MIL-B-18F
Inches
mm
Ltr
Min
Max
Min
Max
A
.017
.023
0.43
0.58
B
.184
.190
4.67
4.82
C
.475
.481
12.07
12.22
D
.324
.330
8.23
8.38
E
.372
.378
9.45
9.60
F
.532
.538
13.51
13.67
G
.091
.095
2.31
2.41
H
.101
.107
2.57
2.72
J
.100
.106
2.54
2.69
K
.684
.690
17.37
17.53
L
.049
.055
1.24
1.40
M
.304
.310
7.72
7.87
N
.122
.128
3.10
3.25
P
.049
.055
1.24
1.40
R
.123
.127
3.12
3.23
NOTES:
1. All dimensions are in inches.
2. Metric equivalents are for general information only.
3. Tolerances are ±.003 inch, except as otherwise specified.
FIGURE 3. Socket terminals - Continued.
