MIL-B-18F
Inches
mm
Ltr
Min
Max
Min
Max
A
.312
.374
7.92
9.50
B
---
.080
---
2.03
C
.330
---
8.38
---
D
.187
.249
4.75
6.32
E
.281
.343
7.14
8.71
F
.016
.078
0.41
1.98
G
.500
.624
12.70
15.85
H
.375
.499
9.53
12.67
NOTES:
1. All dimensions are in inches.
2. Metric equivalents are for general information only.
2. Unless otherwise specified, tolerances are ±.031 inch.
FIGURE 1. Stud and nut terminal - Continued.
