MIL-B-18F
Inches
mm
Ltr
Min
Max
Min
Max
A
.247
.253
6.27
6.43
B
.123
.127
3.12
3.23
C
.154
.158
3.91
4.01
D
.372
.378
9.45
9.60
E
.091
.095
2.31
2.41
F
.477
.503
12.12
12.78
G
.309
.315
7.85
8.00
H
.533
.539
13.54
13.69
NOTES:
1. All dimensions are in inches.
2. Metric equivalents are for general information only.
3. Tolerances are ±.003, except as otherwise specified.
FIGURE 3. Socket terminals (top view) - Continued.
