MIL-B-18/79D
Inches
mm
Ltr
Min
Max
Min
Max
A
.640
.672
16.26
17.07
B
.282
.344
7.163
8.74
C
1.282
1.344
32.56
34.14
D
.062
.188
1.57
4.78
E
3.532
3.626
89.71
92.10
F
.844
---
21.44
---
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Marking to be in accordance with MIL-B-18.
FIGURE 1. Battery dimensions - Continued.
REQUIREMENTS:
Dimensions, marking, and configuration: See figure 1.
Nominal voltage: 1.5 volts.
Usual number and type of cells: 1 "F" cell.
Terminals: Flat surface.
Weight (maximum): 7 ounces.
Capacity tests: When the battery is tested in accordance with the methods of examination and test of
this specification, the minimum capacity-test requirements shall be not less than the minimum time
specified for SLD or SLT.
2
