MIL-B-18/46E
Inches
mm
Ltr
Min
Max
Min
Max
A
2.125
2.251
53.98
63.75
B
1.250
1.376
31.75
34.95
C
3.812
3.938
96.82
100.03
D
.875
1.001
22.23
25.43
E
1.875
2.001
47.63
50.83
F
3.812
3.938
96.82
100.03
G
5.312
5.438
134.92
138.13
H
---
5.938
---
150.83
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerances is ±.0625 (1.59 mm).
4. Marking to be in accordance with MIL-B-18.
FIGURE 1. Battery dimensions - Continued.
REQUIREMENTS:
Dimensions, marking, and configuration: See figure 1.
Nominal voltage: 4.5 volts.
Usual number and type of cells: 12 "F" cells.
Usual cell connection: Series - parallel.
Terminals: Spring clip.
Weight (maximum): 4 pounds, 8 ounces.
Capacity tests: When the battery is tested in accordance with the methods of examination and test of
this specification, the minimum capacity-test requirements shall be not less than the minimum time
specified for SLD or SLT.
